The EOTech BinoNV-W Night Vision Binocular Goggle offers an extra-wide apparent field of view and a sharp, eye-friendly image thanks to its Gen 3 white phosphor light intensifier tubes. The binocular format gives you better depth perception than a monocular for easier navigation in a vehicle or on foot. However, both tubes can be flipped to the side should a monocular format be more advantageous in the circumstances. Situational awareness is enhanced by the 47° field of view, a significant increase over the traditional 40° standard. Power is supplied by one AA battery, which delivers a runtime of 25 hours with a lithium cell or 15 hours with an alkaline cell. The binocular can also be powered by an optional external power supply.
Performance
- 47° field of view for maintaining situational awareness and scanning terrain
- Diopter adjustments suit this optic especially well for special operations forces and SWAT applications
- Dual Gen 3 white phosphor intensifier tubes, 2376 minimum figure of merit
- 10" minimum focus distance allows a user to perform tasks like gear checks and packing/unpacking without giving away their position
Use & Handling
- Both tubes can be flipped to the side when monocular format is preferable
- -6 to +2 dioptric correction on each eyepiece
- Wilcox G24 mount with breakaway design reduces potential for neck injury
- Runs on one AA battery: 25 hours runtime with lithium, 15 hours with alkaline
Key Features
- Optimal Depth Perception
- Both Tubes Flip Up
- Head/Helmet Mountable
- Infrared Illuminator
- Wide & Comfortable 47° Field of View
- 10" Minimum Focus Distance
- Runs on One AA Battery
- EOTech BinoNV-W Night Vision Binocular Goggle with Wilcox G24 Mount (Gen 3 White Phosphor Tube)
- Eyecup Sacrificial Lens
- Wilcox G24 Helmet Mount
- 2 x Lens Cleaning Kit
- Protective Case
- Limited 3-Year Manufacturer Warranty
Gen 3 Night Vision Device Specs
| Lens System | 27.5 mm, f/1.17 |
| Magnification | 1x |
| Angle of View | 40° (Apparent) |
| Minimum Focus Distance | 10" / 0.25 m |
| Eye Relief | 25 mm |
| Interpupillary Adjustment | 52 to 74 mm / 2 to 2.9" |
| Diopter Adjustment | -6 to +5 |
| Infrared Illuminator | Yes (Built-In) |
| Intensifier Tube | 1x Gen 3 |
| Resolution | 64 lp/mm |
| Battery | 2 x AA — Up to 40-Hour Runtime or 2 x CR123A |
| Environmental Resistance | Water-Resistant (Unrated) |
| Operating Conditions | -58 to 131°F / -50 to 55°C |
| Storage Conditions | -58 to 158°F / -50 to 70°C |
| Dimensions | 4.7 x 4.6 x 2.7" / 120 x 118 x 69 mm |
| Weight | 28.5 oz / 725 g |
EOTech BinoNV-W Night Vision Binocular Goggle with Wilcox G24 Mount (Gen 3 White Phosphor Tube)
- Product Code: EOBINOAIBW
The EOTech BinoNV-W Night Vision Binocular Goggle offers an extra-wide apparent field of view and a sharp, eye-friendly image thanks to its Gen 3 white phosphor light intensifier tubes. The binocular format gives you better depth perception than a monocular for easier navigation in a vehicle or on foot. However, both tubes can be flipped to the side should a monocular format be more advantageous in the circumstances. Situational awareness is enhanced by the 47° field of view, a significant increase over the traditional 40° standard. Power is supplied by one AA battery, which delivers a runtime of 25 hours with a lithium cell or 15 hours with an alkaline cell. The binocular can also be powered by an optional external power supply.
Performance
- 47° field of view for maintaining situational awareness and scanning terrain
- Diopter adjustments suit this optic especially well for special operations forces and SWAT applications
- Dual Gen 3 white phosphor intensifier tubes, 2376 minimum figure of merit
- 10" minimum focus distance allows a user to perform tasks like gear checks and packing/unpacking without giving away their position
Use & Handling
- Both tubes can be flipped to the side when monocular format is preferable
- -6 to +2 dioptric correction on each eyepiece
- Wilcox G24 mount with breakaway design reduces potential for neck injury
- Runs on one AA battery: 25 hours runtime with lithium, 15 hours with alkaline
Key Features
- Optimal Depth Perception
- Both Tubes Flip Up
- Head/Helmet Mountable
- Infrared Illuminator
- Wide & Comfortable 47° Field of View
- 10" Minimum Focus Distance
- Runs on One AA Battery
- EOTech BinoNV-W Night Vision Binocular Goggle with Wilcox G24 Mount (Gen 3 White Phosphor Tube)
- Eyecup Sacrificial Lens
- Wilcox G24 Helmet Mount
- 2 x Lens Cleaning Kit
- Protective Case
- Limited 3-Year Manufacturer Warranty
Gen 3 Night Vision Device Specs
| Lens System | 27.5 mm, f/1.17 |
| Magnification | 1x |
| Angle of View | 40° (Apparent) |
| Minimum Focus Distance | 10" / 0.25 m |
| Eye Relief | 25 mm |
| Interpupillary Adjustment | 52 to 74 mm / 2 to 2.9" |
| Diopter Adjustment | -6 to +5 |
| Infrared Illuminator | Yes (Built-In) |
| Intensifier Tube | 1x Gen 3 |
| Resolution | 64 lp/mm |
| Battery | 2 x AA — Up to 40-Hour Runtime or 2 x CR123A |
| Environmental Resistance | Water-Resistant (Unrated) |
| Operating Conditions | -58 to 131°F / -50 to 55°C |
| Storage Conditions | -58 to 158°F / -50 to 70°C |
| Dimensions | 4.7 x 4.6 x 2.7" / 120 x 118 x 69 mm |
| Weight | 28.5 oz / 725 g |
- Brand: EOTech
- Product Code: EOBINOAIBW
- Availability: In Stock
$10,499.00
